General Purpose Relay Plug-In Type 4PDT Built-In Indicator
Product classification: Monostable relays
Built-in LED indicator type | Termination Style: Plug Pin |
Coil: 24 VDC 69 mA |
Mounting Style: Socket |
Max. voltage: 110% (of rated voltage) | Maximum switching current: AC: 10 A,DC: 10 A |
Contact Type: 4PDT | Maximum switching voltage: 250 VAC,125 VDC |
Contact rated load: 110 VAC 10 A (Resistive load (cos phi = 1))
110 VAC 7.5 A (Inductive load (cos phi = 0.4))
24 VDC 10 A (Resistive load)
24 VDC 5 A (Inductive load (L/R = 7 ms)) | Maximum switching power: AC: 1100 VA （Resistive load (cos phi = 1)）
AC: 825 VA （Inductive load (cos phi = 0.4)） |
Protective structure: Closed type (cover) | Operating time (set time) 25ms: |
Applicable standard: (UL) UL508, (CSA) C22.2 No.0, No.14, （TUV） EN61810-1, （SEV） 98.5 50071.02 | Release time (Reset time): 25 ms |
Ambient temperature (Operating) -25 to 40 ℃ | Model: LY4N |
Ambient humidity (Operating) 5 to 85 %RH |
|
